HAH1BVW S/05 LEM Battery Management

HAH1BVW S/05 LEM Battery Management

MOQ: 1PCS
Price: NEGOTIABLE
Standard Packaging: 220PCS/BOX
Delivery Period: 2-3DAYS
Payment Method: T/T, Western Union
Supply Capacity: 2200PCS/WEEK
Detail Information
Place of Origin
CHIAN
Brand Name
LEM
Certification
ROHS
Model Number
HAH1BVW S/05
Operating Temperature Range:
−40 °C < T < 125 °C
Operating Voltage Range:
5V
Accuracy:
1.25 %
Factory Packing Quantity:
220
Product Description





1.Introduction

The HAH1BVW family is for the electronic measurement of DC, AC or pulsed currents in high power and low voltage automotiveapplications with galvanic separation between the primary circuit (high power) and the secondary circuit (electronic circuit).
The HAH1BVW family gives you the choice of having different current measuring ranges in the same housing.

2.Features
●Ratiometric transducer
●Open Loop transducer using the Hall effect
●Low voltage application
●Unipolar +5 V DC power supply
●Primary current measuring range ±500 A
●Maximum RMS primary admissible current: defined by busbar to have T < +150 °C
●Operating temperature range: −40 °C < T < 125 °C
●Output voltage: full ratio-metric (in sensitivity and offset).

3.Advantages
●Excellent accuracy
●Very good linearity
●Very low thermal offset drift
●Very low thermal sensitivity drift
●Galvanic separation
●Non intrusive solution.

4.Automotive application
●Battery Management

5.Principle of HAH1BVW Family
The open loop transducers uses a Hall effect integrated circuit.
The magnetic flux density B, contributing to the rise of the Hall voltage, is generated by the primary current IP to be measured.
The current to be measured IP is supplied by a current source i.e. battery or generator (Figure 1).

HAH1BVW S/05 LEM Battery Management 0



6.Dimensions(in mm)

HAH1BVW S/05 LEM Battery Management 1

HAH1BVW S/05 LEM Battery Management 2
