MT7603EN/B MTK Wi Fi single chip, supporting 300 Mbps PHY rate

1.The MT7603 is a highly integrated Wi Fi single chip that supports a PHY rate of 300 Mbps. It fully complies with IEEE 802.11n and IEEE 802.11 b/g standards, provides high standard and functional wireless connectivity, and provides reliable, stable and cost-effective processing capability from a longer distance. The optimized RF architecture and baseband algorithm bring excellent performance, as well as reliable and low-power processing capability. Its intelligent media access control (MAC) design adopts a highly efficient direct memory access (DMA) engine, and is also equipped with a hardware information processing accelerator that can reduce the load of the main processor

2.MT7603 platform features:
System:
Embedded High Performance 32-bit rISC Microprocessor
55 nm CMOS process high integrated RF
Integrated high efficiency switch regulator
Optimal intra stage active and idle power consumption performance
Compact 7mm x 7mm QFN56L package
LTE Coexistence(UART)
Antenna detection
Combined with other SOC chips as buffered clock output
Integrated eFuse eliminates external EEProm requirements
16 Programmable Universal I/O
2 configurable LED pins
Automatic calibration
Free calibration (saving MP cost)

3.WLAN:
IEEE 802.11 b/g/n compatible
Support 2T2R mode of 300 Mbps PHY rate
Green space, mixed mode and legacy mode support
Support MCC (multi-channel concurrency)
Frame aggregation
BW5/10 narrowband (Rx 2.5dBm), expanded coverage
WWLAN supports host sleep (AP mode) through GPIO (client mode)
Airtime Fairness(QoS)
Meet ETSI en 300 328 V1.8.1 test plan (mandatory for EU in 2014/E)
Integrated LNA, PA and T/R switches
Ieee 802.11 d/h/k support
Security support of WFA WPA/WPA 2 people, WPS2.0 and WAPI
Support 802.11w protected managed frames
QoS support of WFA WMM and WMM PS
Support Wi Fi direct
Power control per packet transmission
