STM32F407ZGT6 ST ARM Microcontrollers - MCU ARM M4 1024 FLASH 168 Mhz 192kB SRAM

STM32F407ZGT6 ST ARM Microcontrollers - MCU ARM M4 1024 FLASH 168 Mhz 192kB SRAM

  • STM32F407ZGT6 ST ARM Microcontrollers - MCU ARM M4 1024 FLASH 168 Mhz 192kB SRAM
  • STM32F407ZGT6 ST ARM Microcontrollers - MCU ARM M4 1024 FLASH 168 Mhz 192kB SRAM
STM32F407ZGT6 ST ARM Microcontrollers - MCU ARM M4 1024 FLASH 168 Mhz 192kB SRAM
Product Details:
Place of Origin: TAIWAN
Brand Name: ST
Certification: ROHS
Model Number: STM32F407ZGT6
Payment & Shipping Terms:
Minimum Order Quantity: 10PCS
Price: NEGOTIABLE
Packaging Details: 360PCS/BOX
Delivery Time: 2-3DAYS
Payment Terms: T/T, Western Union
Supply Ability: 2520PCS/WEERK
Contact Now
Detailed Product Description
Package / Case: LQFP-144 Core: ARM Cortex M4
Program Memory Size: 1 MB Data Bus Width: 32 Bit
ADC Resolution: 12 Bit Maximum Clock Frequency: 168 MHz
Number Of I/Os: 114 I/O Data RAM Size: 192 KB
Supply Voltage - Min: 1.8 V Supply Voltage - Max: 3.6 V
Minimum Operating Temperature: - 40 C Maximum Operating Temperature: + 85 C
DAC Resolution: 12 Bit Number Of ADC Channels: 24 Channel
Product: MCU+FPU Program Memory Type: Flash
Factory Packing Quantity: 360

STM32F407ZGT6 ST ARM Microcontrollers - MCU ARM M4 1024 FLASH 168 Mhz 192kB SRAM



1.Features
•Core: Arm® 32-bit Cortex®-M4 CPU with FPU, Adaptive real-time accelerator (ART Accelerator) allowing 0-wait state execution from Flash memory, frequency up to 168 MHz, memory protection unit, 210 DMIPS/1.25 DMIPS/MHz(Dhrystone 2.1), and DSP instructions



Memories
– Up to 1 Mbyte of Flash memory
– Up to 192+4 Kbytes of SRAM including 64-Kbyte of CCM (core coupled memory) data RAM
– 512 bytes of OTP memory
– Flexible static memory controller supporting Compact Flash, SRAM, PSRAM, NOR and NAND memories



LCD parallel interface, 8080/6800 modes
Clock, reset and supply management
– 1.8 V to 3.6 V application supply and I/Os
– POR, PDR, PVD and BOR
– 4-to-26 MHz crystal oscillator
– Internal 16 MHz factory-trimmed RC (1% accuracy)
– 32 kHz oscillator for RTC with calibration
– Internal 32 kHz RC with calibration



Low-power operation
– Sleep, Stop and Standby modes
–VBAT supply for RTC, 20×32 bit backup registers + optional 4 KB backup SRAM
•3×12-bit, 2.4 MSPS A/D converters: up to 24 channels and 7.2 MSPS in triple interleaved mode
•2×12-bit D/A converters
•General-purpose DMA: 16-stream DMA controller with FIFOs and burst support



Up to 17 timers: up to twelve 16-bit and two 32-bit timers up to 168 MHz, each with up to 4 IC/OC/PWM or pulse counter and quadrature (incremental) encoder input



Debug mode
– Serial wire debug (SWD) & JTAG interfaces
– Cortex-M4 Embedded Trace Macrocell™
•Up to 140 I/O ports with interrupt capability
– Up to 136 fast I/Os up to 84 MHz
– Up to 138 5 V-tolerant I/Os
•Up to 15 communication interfaces
– Up to 3 × I2C interfaces (SMBus/PMBus)
– Up to 4 USARTs/2 UARTs (10.5 Mbit/s, ISO 7816 interface, LIN, IrDA, modem control)
– Up to 3 SPIs (42 Mbits/s), 2 with muxed full-duplex I2S to achieveaudio class accuracy via internal audio PLL or external clock
– 2 × CAN interfaces (2.0B Active)
– SDIO interface



Advanced connectivity
– USB 2.0 full-speed device/host/OTG controller with on-chip PHY
– USB 2.0 high-speed/full-speed device/host/OTG controller with dedicated DMA, on-chip full-speed PHY and ULPI
– 10/100 Ethernet MAC with dedicated DMA: supports IEEE 1588v2 hardware, MII/RMII

8- to 14-bit parallel camera interface up to 54 Mbytes/s
•True random number generator•CRC calculation unit
•96-bit unique ID
•RTC: subsecond accuracy, hardware calendar





STM32F407ZGT6 ST ARM Microcontrollers - MCU ARM M4 1024 FLASH 168 Mhz 192kB SRAM 0
