|Place of Origin:||CHINA|
|Minimum Order Quantity:||10PCS|
|Payment Terms:||T/T, Western Union|
|Product:||Non Isolated POL||Number Of Outputs:||1 Output|
|Input Voltage, Nominal:||15 V||Input Voltage, Min:||9 V|
|Input Voltage, Max:||24 V||Output Voltage-Channel 1:||- 3.3 V To - 18 V|
|Output Current-Channel 1:||5 A||Minimum Operating Temperature:||- 40 C|
|Maximum Operating Temperature:||+ 85 C||Length:||20.3 Mm|
|Width:||11.4 Mm||Height:||8.5 Mm|
|Input Voltage:||9 V To 24 V||Output Type:||Programmable|
|Industry:||Industrial||Factory Pack Quantity:||250|
IPC 9592 DC DC Converters,
ABB Non Isolated DC DC Converters,
APXW005A0X3-SRZ Non Isolated POL
APXW005A0X3-SRZ ABB Non-Isolated DC/DC Converters
1. 9-36V ProLynxTM5A:Non-Isolated DC-DC Power Modules 9Vdc –36Vdc input; 3Vdc to 18Vdc output; 5Ato 2.5AScaled output current 9Vdc –24Vdc input; -3.3Vdc to -18Vdc output1; 5Ato 0.7AScaled output current
• Compliant to RoHS Directive 2011/65/EU and amended Directive(EU) 2015/863
• Compliant to REACH Directive (EC) No 1907/2006
• Compatible in a Pb-free or SnPb reflow environment (Z versions)
• Compliant to IPC-9592 (September 2008), Category 2, Class II
• Extra Wide Input voltage range (9Vdc–36Vdc)
• Output voltage programmable from 3Vdc to 18 Vdc via external resistor
• Tunable LoopTMto optimize dynamic output voltage response
• Patent Pending AutoLimitautomatic scaling of current limit with output voltage
• Output overcurrent protection (non-latching)
• Overtemperature protection•Remote On/Off
• Remote Sense•Small size: 20.3 mm x 11.4 mm x 8.5 mm (0.8 in x 0.45 in x 0.335 in)
• Wide operating temperature range [-40°C to105°C(Ruggedized: -D), 85°C(Regular)]
• UL* 60950-1,2ndEd. Recognized, CSA†C22.2 No. 60950-1-07 Certified, and VDE‡(EN60950-1, 2ndEd.) Licensed
• ISO** 9001 and ISO 14001 certified manufacturing facilities
• Industrial equipment
• Distributed power architectures
• Intermediate bus voltage applications
• Telecommunications equipment
9-36V ProLynxTM5A:Non-Isolated DC-DC Power Modules9Vdc –36Vdc input; 3Vdc to 18Vdc output; 5Ato 2.5AScaled output current 9Vdc –24Vdc input; -3.3Vdc to -18Vdc output1; 5Ato 0.7AScaled output current9-3V ProLynxTM5A:Non-Isolated DC-DC Power Modules9Vdc –36Vdc input; 3Vdc to 18Vdc output; 5Ato 2.5AScaled output current 9Vdc –24Vdc input; -3.3Vdc to -18Vdc output1; 5Ato 0.7AScaled output current
The 9-36V ProLynxTMseries of power modules are non-isolated dc-dc converters that can deliver up to 5A of output current. These modules operate over an extra wide range of input voltage (VIN= 9Vdc –36Vdc) and provide a precisely regulated output voltage from 3Vdc to 18Vdc, programmable via an external resistor. Two new features added with this family of products are the ability to externally tune the voltage control loop and a variable current limit inversely dependenton output voltage. Other features include remote On/Off, adjustable output voltage, over current and over temperature protection. The Ruggedized version (-D) is capable of operation up to 105°C and withstand high levels of shock and vibration. The Tunable LoopTM, allows the user to optimize the dynamic response of the converter to match the load with reduced amount of output capacitance leading to savings on cost and PWB area and AutoLimit enables the module to deliver the max possible output power across the entire voltage range. The 9-36V ProLynx can alsobe used for negative output voltageloads through the use of a specific application schematic
