LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original

LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original

MOQ: 10PCS
Price: NEGOTIABLE
Standard Packaging: 2500PC/REEL
Delivery Period: 2-3DAYS
Payment Method: T/T, Western Union
Supply Capacity: 12500PCS/WEEK
Detail Information
Place of Origin
Mexico
Brand Name
Texas Instruments
Certification
ROHS
Model Number
LM339ADR
Features:
Standard Comparator
Product Category:
Analog Comparators
Number Of Channels:
4 Channel
Output Type:
Rail-to-Rail
Response Time:
300 Ns
Comparator Type:
Differentia
Supply Voltage - Min:
2 V
Supply Voltage - Max:
30 V
Operating Supply Current:
500 UA
Output Current Per Channel:
6 MA
Vos - Input Offset Voltage:
2 MV
Ib - Input Bias Current:
50 NA
Minimum Operating Temperature:
0 C
Maximum Operating Temperature:
+ 70 C
Height:
1.58 Mm
Length:
8.65 Mm
Product:
Analog Comparators
Supply Type:
Single, Dual
Technology:
Bipolar
Type:
Differential Comparator
Width:
3.91 Mm
Shutdown:
No Shutdown
Dual Supply Voltage:
+/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V
Ios - Input Offset Current:
50 NA
Maximum Dual Supply Voltage:
+/- 15 V
Minimum Dual Supply Voltage:
1 V
Operating Supply Voltage:
2 V To 30 V
Product Type:
Analog Comparator
Voltage Gain DB:
106.02 DB
Factory Pack Quantit:
2500
Highlight:

Texas Instruments Analog Comparators

,

LM339ADR Analog Comparators

,

4 Channel Analog Devices Comparators

Product Description

  LM339ADR Texas Instruments Analog Comparators 100% Original​  Analog Comparators Quad Diff A Grade

1.Features
1• Wide Supply Ranges
– Single Supply: 2 V to 36 V
(Tested to 30 V for Non-V Devices and
32 V for V-Suffix Devices)
– Dual Supplies: ±1 V to ±18 V
(Tested to ±15 V for Non-V Devices and
±16 V for V-Suffix Devices)
• Low Supply-Current Drain Independent of
Supply Voltage: 0.8 mA (Typical)
• Low Input Bias Current: 25 nA (Typical)
• Low Input Offset Current: 3 nA (Typical) (LM139)
• Low Input Offset Voltage: 2 mV (Typical)
• Common-Mode Input Voltage Range
Includes Ground
• Differential Input Voltage Range Equal to
Maximum-Rated Supply Voltage: ±36 V
• Low Output Saturation Voltage
• Output Compatible With TTL, MOS, and CMOS
• On Products Compliant to MIL-PRF-38535,
All Parameters Are Tested Unless Otherwise
Noted. On All Other Products, Production
Processing Does Not Necessarily Include Testing
of All Parameters

2.Applications
• Industrial
• Automotive
– Infotainment and Clusters
– Body Control Modules
• Power Supervision
• Oscillators
• Peak Detectors
• Logic Voltage Translation

3.Description
The LMx39x and the LM2901x devices consist of four
independent voltage comparators that are designed
to operate from a single power supply over a wide
range of voltages. Operation from dual supplies also
is possible, as long as the difference between the two
supplies is 2 V to 36 V, and VCC is at least 1.5 V
more positive than the input common-mode voltage.
Current drain is independent of the supply voltage.
The outputs can be connected to other open-collector
outputs to achieve wired-AND relationships.
The LM139 and LM139A devices are characterized
for operation over the full military temperature range
of –55°C to +125°C. The LM239 and LM239A
devices are characterized for operation from –25°C to
+85°C. The LM339 and LM339A devices are
characterized for operation from 0°C to 70°C. The
LM2901, LM2901AV, and LM2901V devices are
characterized for operation from –40°C to +125°C.



4.Device Information(1)

LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original 0



5.Pin Configuration and Functions

LM339ADR Texas Instruments Analog Comparators 4 Channel 100% Original 1



7.Why choose us?

100% new and originao with Advantage price
High efficiency
Fast Delivery
Professional team service
10 Years Experience Electronic components
Electronic components Agent
Advantage logistic discount
Excellent After-sales Service.
