| MOQ: | 10PCS |
| Price: | NEGOTIABLE |
| Standard Packaging: | 1000PCS/REEL |
| Delivery Period: | 2-3DAYS |
| Payment Method: | T/T, Western Union |
| Supply Capacity: | 10000PCS/WEEK |
MSP430F413IPMR 100% Original 16-bit Microcontrollers - MCU 8kB Flash 256B RAM Comp/96 segment LCD
1.Low Supply-Voltage Range, 1.8 V to 3.6 V
Ultralow Power Consumption− Active Mode: 200 μA at 1 MHz, 2.2 V− Standby Mode: 0.7 μA− Off Mode (RAM Retention): 0.1 μA
Five Power-Saving Modes
Wake-Up From Standby Mode in Less Than 6 μs
Frequency-Locked Loop (FLL+)
16-Bit RISC Architecture, 125-nsInstruction Cycle Time
16-Bit Timer_A With Three or Five†Capture/Compare Registers
Integrated LCD Driver for 96 Segments
On-Chip Comparator
Brownout Detector
Supply Voltage Supervisor/Monitor −Programmable Level Detection onMSP430F415/417 Devices Only† Timer_A5 in ’F415 and ’F417 devices only
2.description
The Texas Instruments MSP430 family of ultra-low-power microcontrollers consists of several devices featuringdifferent sets of peripherals targeted for various applications. The architecture, combined with five low powermodes, is optimized to achieve extended battery life in portable measurement applications. The device featuresa powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to maximum codeefficiency.The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in lessthan 6 μs.The MSP430x41x series are microcontroller configurations with one or two built-in 16-bit timers, a comparator,96 LCD segment drive capability, and 48 I/O pins.Typical applications include sensor systems that capture analog signals, convert them to digital values, andprocess the data and transmit them to a host system. The comparator and timer make the configurations idealfor industrial meters, counter applications, handheld meters, etc
3.
3.
4.Why choose us?
100% new and originao with Advantage price
High efficiency
Fast Delivery
Professional team service
10 Years Experience Electronic components
Electronic components Agent
Advantage logistic discount
Excellent After-sales Service
|
|
