75A 6V 100A Imax Resettable Fuses PPTC NANOSMDC075F-2

75A 6V 100A Imax Resettable Fuses PPTC NANOSMDC075F-2

MOQ: 10PCS
Price: NEGOTIABLE
Standard Packaging: 3000PCS/REEL
Delivery Period: 2-3DAYS
Payment Method: T/T, Western Union
Supply Capacity: 12000PCS/WEEK
Detail Information
Place of Origin
CHINA
Brand Name
Littelfuse
Certification
ROHS
Model Number
NANOSMDC075F-2
Hold Current:
750 MA
Maximum Voltage:
6V
Trip Current:
1.5 A
Current Rating - Max:
100 A
Resistance:
300 MOhms
Minimum Operating Temperature:
- 40 C
Maximum Operating Temperature:
+ 80 C
Height:
0.68 Mm
Length:
3.4 Mm
Width:
1.8 Mm
Pd - Power Dissipation:
800 MW
Factory Pack Quantity:
3000
Highlight:

100A Imax Resettable Fuses

,

Resettable Fuses PPTC

,

NANOSMDC075F-2

Product Description

NANOSMDC075F-2 Resettable Fuses - PPTC .75A 6V 100A Imax Used in computers, consumer, multimedia, portable and automotive

1.PolySwitch surface-mount devices are an effective circuit protection method for computer, consumer, multimedia, portable and automotive electronics applications.In an affort to reduce the size and cost of surface-mount devices, Littelfuse PolySwitch team introduced the miniSMD product series in 1995. Subsequently, we developed the microSMD, nanoSMD, picoSMD and femtoSMD family of products. The femtoSMD series reduced the device size to a 1608mm (0603 mils) footprint, which is one-twelfth the size of the popular miniSMD series.Recent additions to the PolySwitch surface-mount series include 1.1A picoSMD 1210mm (0805 mils) and 0.35A femtoSMD 1608mm (0603 mils) devices

2.BENEFITS
Smaller size helps save board space and cost
Many product choices optimizes design flexibility
Compatible with high-volume electronics assembly
Assists in meeting regulatory requirements
Higher voltage ratings allow use in new application

3.FEATURES
RoHS compliant
Halogen free (refers to: Br≥900ppm, Cl≥900ppm, Br+Cl≥1500ppm)
Broadest range of resettable devices available in the industry
Current ratings from 0.05 to 3.1A
Voltage ratings from 6V computer and electronic applications to 60V telecom applications
Agency recognition: UL, CSA, TÜV
Small footprint
Fast time-to-trip
Low resistanc

4.APPLICATIONS
Computer
Portable electronics
Multimedia
Game machines
Telephony and broadband
Mobile phones
Automotive
Industrial controls
Batter
