Shenzhen Hongxinwei Technology Co., Ltd
To adopt new technology,to produce products of quality,to offer high-class service.
 |
| Place of Origin: | Mexico |
| Brand Name: | Texas Instruments |
| Certification: | ROHS |
| Model Number: | TLV2374IDR |
| Minimum Order Quantity: | 10PCS |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | 2500PC/REEL |
| Delivery Time: | 2-3DAYS |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 20000PCS/WEEK |
| Package / Case: | SOIC-14 | Output Current Per Channel: | 16 MA |
|---|---|---|---|
| Vos - Input Offset Voltage: | 4.5 MV | Minimum Operating Temperature: | - 40 C |
| Maximum Operating Temperature: | + 125 C | Ib - Input Bias Current: | 60 PA |
| Operating Supply Current: | 750 UA | CMRR - Common Mode Rejection Ratio: | 84 DB |
| Amplifier Type: | General Purpose Amplifier | Height: | 1.58 Mm |
| Input Type: | Rail-to-Rail | Length: | 8.65 Mm |
| Output Type: | Rail-to-Rail | Supply Type: | Single, Dual |
| Width: | 3.91 Mm | Dual Supply Voltage: | +/- 3 V, +/- 5 V |
| In - Input Noise Current Density: | 0.0006 PA/sqrt Hz | Maximum Dual Supply Voltage: | +/- 8 V |
| Minimum Dual Supply Voltage: | +/- 1.35 V | Operating Supply Voltage: | 2.7 V To 16 V, +/- 1.35 V To +/- 8 V |
| Pd - Power Dissipation: | 1022 MW | PSRR - Power Supply Rejection Ratio: | 70 DB |
| Voltage Gain DB: | 110 DB | Factory Pack Quantity: | 2500 |
1.Features
1• Rail-to-RailInputand Output
• WideBandwidth:3 MHz
• HighSlewRate:2.4 V/μs
• SupplyVoltageRange:2.7 V to 16 V
• SupplyCurrent:550μA/Channel
• Low-PowerShutdownMode– IDD(SHDN): 25μA/Channel
• InputNoiseVoltage:39 nV/√Hz
• InputBiasCurrent:1 pA
• SpecifiedTemperatureRange:–−40°C to +125°C (IndustrialGrade)
• Ultra-SmallPackaging:– 5- or 6-PinSOT-23(TLV2370,TLV2371)– 8- or 10-PinMSOP(TLV2372,TLV2373
2.Applications
• WhiteGoods
• HandheldTestEquipment
• PortableBloodGlucoseSystems
• RemoteSensing
• Active Filters
• IndustrialAutomation
• Battery-PoweredElectronics
3.Description
TheTLV237xsingle-supplyoperationalamplifiersproviderail-to-railinputandoutputcapability.TheTLV237xtakesthe minimumoperatingsupplyvoltagedownto 2.7V overtheextendedindustrialtemperaturerangewhileaddingthe rail-to-railoutputswingfeature.TheTLV237xalsoprovides3-MHzbandwidthfromonly550μA. Themaximumrecommendedsupplyvoltageis 16 V, whichallowsthe devicesto be operatedfrom(±8-V suppliesdownto ±1.35V) a varietyof rechargeablecells.
TheCMOSinputsenableusein high-impedancesensorinterfaces,withthe lowervoltageoperationmakingan idealalternativefor the TLC227xinbattery-poweredapplications.Therail-to-railinputstagefurtherincreasesits versatility.The TLV237xisthe seventhmemberof a rapidlygrowingnumberofRRIOproductsavailablefromTI, and it is the first toallowoperationup to 16-Vrailswithgoodacperformance.
All membersare availablein PDIPand SOICwith thesinglesin the smallSOT-23package,dualsin theMSOP,and quadsin the TSSOPpackage.
The 2.7-Voperationmakesthe TLV237xcompatiblewith Li-Ionpoweredsystemsand the operatingsupplyvoltagerangeof manymicro-powermicrocontrollersavailabletodayincludingTI’s MSP430
4.
