IRFR540ZTRPBF 100V 35A 39nC Qg N Channel MOSFT Lead Free
  • name
  • name
  • name

IRFR540ZTRPBF 100V 35A 39nC Qg N Channel MOSFT Lead Free

MOQ: 10PCS
Price: NEGOTIABLE
Standard Packaging: 2000PCS/REEL
Delivery Period: 2-3DAYS
Payment Method: T/T, Western Union
Supply Capacity: 20000PCS/WEEK
Details Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
Infineon
Certification
ROHS
Model Number
IRFR540ZTRPBF
Transistor Polarity:
N-Channel
Number Of Channels:
1 Channel
Vds - Drain-Source Breakdown Voltage:
100 V
Id - Continuous Drain Current:
35 A
Rds On - Drain-Source Resistance:
28.5 MOhms
Vgs - Gate-Source Voltage:
- 20 V, + 20 V
Vgs Th - Gate-Source Threshold Voltage:
4 V
Qg - Gate Charge:
59 NC
Minimum Operating Temperature:
- 55 C
Maximum Operating Temperature:
+ 175 C
Pd - Power Dissipation:
91 W
Channel Mode:
Enhancement
Configuration:
Single
Height:
2.3 Mm
Length:
6.5 Mm
Transistor Type:
1 N-Channel
Width:
6.22 Mm
Forward Transconductance - Min:
28 S
Fall Time:
34 Ns
Rise Time:
42 Ns
Factory Pack Quantity:
2000
Highlight:

35A N Channel MOSFT

,

39nC Qg N Channel MOSFT

,

IRFR540ZTRPBF 1 Channel MOSFT

Product Description

IRFR540ZTRPBF

1.Features
Advanced Process Technology
Ultra Low On-Resistance
175°C Operating Temperature
Fast Switching
Repetitive Avalanche Allowed up to Tjmax
Lead-Free
Halogen-Free

2.Description
This HEXFET® Power MOSFET utilizes the latestprocessing techniques to achieve extremely lowon-resistance per silicon area. Additional featuresof this design are a 175°C junction operatingtemperature, fast switching speed and improvedrepetitive avalanche rating. These featurescombine to make this design an extremely efficientand reliable device for use in a wide variety ofapplications.SDG

3.IRFR540ZTRPBF 100V 35A 39nC Qg N Channel MOSFT Lead Free 0

IRFR540ZTRPBF 100V 35A 39nC Qg N Channel MOSFT Lead Free 1

4Why choose us?

100% new and originao with Advantage price
High efficiency
Fast Delivery
Professional team service
10 Years Experience Electronic components
Electronic components Agent
Advantage logistic discount
Excellent After-sales Service
