TPS60400QDBVRQ1 60mA Switching Voltage Regulators 50kHz

TPS60400QDBVRQ1 60mA Switching Voltage Regulators 50kHz

MOQ: 10PCS
Price: NEGOTIABLE
Standard Packaging: 3000PCS/REEL
Delivery Period: 2-3DAYS
Payment Method: T/T
Supply Capacity: 12000PCS/WEEK
Detail Information
Place of Origin
TAIWAN
Brand Name
TI
Certification
ROHS
Model Number
TPS60400QDBVRQ1
Output Voltage:
- 1.8 V To - 5.25 V
Output Current:
60 MA
Number Of Outputs:
1 Output
Input Voltage MAX:
5.25 V
Input Voltage MIN:
1.8 V
Switching Frequency:
50kHz To 250 KHz
Minimum Operating Temperature:
- 40 C
Maximum Operating Temperature:
+ 125 C
Height:
1.15 Mm
Length:
2.9 Mm
Width:
1.6 Mm
Operating Supply Current:
125 UA
Factory Pack Quantity:
3000
Highlight:

60mA Switching Voltage Regulators

,

TPS60400QDBVRQ1 Switching Voltage Regulators

,

50kHz Voltage Regulators IC

Product Description

  TPS60400QDBVRQ1 Switching Voltage Regulators Auto Cat Unreg 60mA Chg Pump Vltg Invrtr

1.Features

Qualifiedfor AutomotiveApplications
• AEC-Q100TestGuidanceWiththe FollowingResults:
– DeviceTemperatureGrade1:
–40°C to+125°C AmbientOperatingTemperatureRange
– Device HBM ESD Classification Level2
– Device CDM ESD Classification LevelC6
• InvertsInputSupplyVoltage
• Up to 60-mAOutputCurrent
• OnlyThreeSmall1-μF CeramicCapacitorsNeeded
• Input Voltage Range From1.8 V to 5.25V
• PowerSave-Modefor ImprovedEfficiencyat LowOutputCurrents(TPS60400-Q1)
• DeviceQuiescentCurrentTypical:100 μA
• IntegratedActiveSchottky-Diodefor Start-UpIntoLoad
• Small5-PinSOT23Package

2.Applications
• AutomotiveInfotainment
• AutomotiveCluster
• LCDDisplays
• NegativeSupplyVoltages

3.Description

TheTPS6040x-Q1familyof devicesgenerateanunregulatednegativeoutputvoltagefroman inputvoltagerangingfrom1.8 V to 5.25V. The devicesaretypicallysuppliedby a preregulatedsupplyrail of 5 Vor 3.3 V. Dueto its wide-inputvoltagerange,two orthreeNiCd,NiMH,or alkalinebatterycells,as well asone Li-Ioncell, can also powerthem.
Onlythreeexternal1-μF capacitorsare requiredtobuilda completeDC-DCchargepumpinverter.Assembledin a 5-pinSOT-23package,the completeconvertercanbe builton a 50-mm2boardarea.Replacingthe Schottkydiodetypicallyneededforstart-upinto loadwith integratedcircuitrycan achieveadditionalboardareaandcomponentcountreduction.
TheTPS6040x-Q1can delivera maximumoutputcurrentof 60 mA, with a typicalconversionefficiencyof greaterthan90%overa wideoutputcurrentrange.ThreedeviceoptionsTPS60401/2/3-Q1with 20-kHz,50-kHz,and 250-kHzfixedfrequencyoperationareavailable.TPS60400-Q1devicecomeswithavariableswitchingfrequencyto reduceoperatingcurrentin applicationswitha wideloadrangeandenablesthe designwith low-valuecapacitors

4.Typical Application Circuit

TPS60400QDBVRQ1 60mA Switching Voltage Regulators 50kHz 0

5.Output Voltage vs Input Voltage

TPS60400QDBVRQ1 60mA Switching Voltage Regulators 50kHz 1
