Name: 500000dpi Sony600 Line Surveillance Camera Motherboard NVP2041+ICX639BK
Brand: Sony
SKU: NVP2041+ICX639BK

Home Products PCB Prototype

500000dpi Sony600 Line Surveillance Camera Motherboard NVP2041+ICX639BK

Product Details:

Place of Origin:	CHINA
Brand Name:	Sony
Certification:	ROHS
Model Number:	NVP2041+ICX639BK

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	NEGOTIABLE
Packaging Details:	480PCS/BOX
Delivery Time:	2-3DAYS
Payment Terms:	T/T, Western Union
Supply Ability:	48000PCS/WEEK

Contact Now

Detailed Product Description

Pixel:	500000 (dpi)	Types Of:	Monitor Motherboard
Style:	Board	Horizontal Resolution:	600 (TVL)
Minimum Illumination:	0.01 (Lux)
High Light:	Sony600 Line Surveillance Camera Motherboard , 500000dpi Surveillance Camera Motherboard , CCD Motherboard

NVP2041+ICX639BK 1/3Sony Sony 600 Line Surveillance Camera Motherboard NVP2041+ICX639BK, CCD Motherboard

1.1. Product name 2041+639

2. Main control DSP NVP2041

3.AFE None

4. Signal System Signal System PAL System NTSC System

5. Sensor ICX639BK ICX638BK 6

. Pixels 752H×582V (PAL) 768H×494V (NTSC)

7. Resolution Horizontal Resolution 600TVL

8. Minimum lllumination 0.01Lux

9.OSD menu support

10.Electronic shutter 1/50(1/60)-1/100000 second

11. Automatic white balance White balance ON/OFF

12. Automatic gain AGC ON/OFF

13. Backlight compensation ON/OFF

14. Auto Iris No

15. Sync System lnternal

16. S/N Ratio ≥48dB

17. Power Supply DC12V

18 Operating Current 50mA

19. Operation Temperature -20℃-+60℃

20. Size 32mm×38mm

2.Why choose us?

100% new and originao with Advantage price
High efficiency
Fast Delivery
Professional team service
10 Years Experience Electronic components
Electronic components Agent
Advantage logistic discount
Excellent After-sales Service
