| MOQ: | 10PCS |
| Price: | Negotiable |
| Standard Packaging: | 2500PC/REEL |
| Delivery Period: | 2-3DAYS |
| Payment Method: | T/T, Western Union |
| Supply Capacity: | 100000PCCS/WEEK |
1.Features
• Up to 95% Efficiency
• Input Voltage Range: 4.4V to 30V
• 1A Output Current Capability
• Output Voltage Range: 2.0V to 24V
• Qualification: AEC-Q100 Rev. G, Grade 1(-40°C to +125°C)
• Integrated N-Channel High-Side and Low-Side Switches:-170m, Low Side-300m, High Side
• Stable Reference Voltage: 0.8V
• Automatic Pulse Frequency Modulation/Pulse-Width Modulation (PFM/PWM) Operation (MCP16311):- PFM Operation Disabled (MCP16312)- PWM Operation: 500 kHz
• Low Device Shutdown Current: 3 μA Typical
Low Device Quiescent Current:- 44 μA (Non-switching, PFM Mode)
• Internal Compensation• Internal Soft-Start: 300 μs (EN Low-to-High)• Peak Current Mode Control
• Cycle-by-Cycle Peak Current Limit
• Undervoltage Lockout (UVLO):- 4.1V typical to start- 3.6V typical to stop
• Overtemperature Protection
• Thermal Shutdown:- +150°C- +25°C Hysteresis
2.Applications
•PIC®/dsPIC® Microcontroller Bias Supply
• 24V Industrial Input DC-DC Conversion
• General Purpose DC-DC Conversion
• Local Point of Load Regulation
• Automotive Battery Regulation
• Set-Top Boxes
Cable Modems
• Wall Transformer Regulation
• Laptop Computers
• Networking Systems
• AC-DC Digital Control Bias
• Distributed Power Supplies
3.General Description
The MCP16311/2 is a compact, high-efficiency, fixedfrequency, synchronous step-down DC-DC converter inan 8-pin MSOP, or 2 x 3 mm TDFN package thatoperates from input voltage sources up to 30V.Integrated features include a high-side and a low-sideswitch, fixed frequency peak current mode control,internal compensation, peak current limit andovertemperature protection. The MCP16311/2 providesall the active functions for local DC-DC conversion, withfast transient response and accurate regulation.High converter efficiency is achieved by integrating thecurrent-limited, low-resistance, high-speed high-sideand low-side switches and associated drive circuitry.The MCP16311 is capable of running in PWM/PFMmode. It switches in PFM mode for light loadconditions and for large buck conversion ratios. Thisresults in a higher efficiency over all load ranges. TheMCP16312 runs in PWM-only mode, and isrecommended for noise-sensitive applications.The MCP16311/2 can supply up to 1Aof continuouscurrent while regulating the output voltage from 2V to12V. An integrated, high-performance peak currentmode architecture keeps the output voltage tightlyregulated, even during input voltage steps and outputcurrent transient conditions common in power systems.The EN input is used to turn the device on and off.While off, only a few micro amps of current areconsumed from the input.Output voltage is set with an external resistor divider.The MCP16311/2 is offered in small MSOP-8 and2 x 3 mm TDFN surface mount packages.
2.Typical Applications
3.Why choose us?
100% new and originao with Advantage price
High efficiency
Fast Delivery
Professional team service
10 Years Experience Electronic components
Electronic components Agent
Advantage logistic discount
Excellent After-sales Service.
|
|
| MOQ: | 10PCS |
| Price: | Negotiable |
| Standard Packaging: | 2500PC/REEL |
| Delivery Period: | 2-3DAYS |
| Payment Method: | T/T, Western Union |
| Supply Capacity: | 100000PCCS/WEEK |
1.Features
• Up to 95% Efficiency
• Input Voltage Range: 4.4V to 30V
• 1A Output Current Capability
• Output Voltage Range: 2.0V to 24V
• Qualification: AEC-Q100 Rev. G, Grade 1(-40°C to +125°C)
• Integrated N-Channel High-Side and Low-Side Switches:-170m, Low Side-300m, High Side
• Stable Reference Voltage: 0.8V
• Automatic Pulse Frequency Modulation/Pulse-Width Modulation (PFM/PWM) Operation (MCP16311):- PFM Operation Disabled (MCP16312)- PWM Operation: 500 kHz
• Low Device Shutdown Current: 3 μA Typical
Low Device Quiescent Current:- 44 μA (Non-switching, PFM Mode)
• Internal Compensation• Internal Soft-Start: 300 μs (EN Low-to-High)• Peak Current Mode Control
• Cycle-by-Cycle Peak Current Limit
• Undervoltage Lockout (UVLO):- 4.1V typical to start- 3.6V typical to stop
• Overtemperature Protection
• Thermal Shutdown:- +150°C- +25°C Hysteresis
2.Applications
•PIC®/dsPIC® Microcontroller Bias Supply
• 24V Industrial Input DC-DC Conversion
• General Purpose DC-DC Conversion
• Local Point of Load Regulation
• Automotive Battery Regulation
• Set-Top Boxes
Cable Modems
• Wall Transformer Regulation
• Laptop Computers
• Networking Systems
• AC-DC Digital Control Bias
• Distributed Power Supplies
3.General Description
The MCP16311/2 is a compact, high-efficiency, fixedfrequency, synchronous step-down DC-DC converter inan 8-pin MSOP, or 2 x 3 mm TDFN package thatoperates from input voltage sources up to 30V.Integrated features include a high-side and a low-sideswitch, fixed frequency peak current mode control,internal compensation, peak current limit andovertemperature protection. The MCP16311/2 providesall the active functions for local DC-DC conversion, withfast transient response and accurate regulation.High converter efficiency is achieved by integrating thecurrent-limited, low-resistance, high-speed high-sideand low-side switches and associated drive circuitry.The MCP16311 is capable of running in PWM/PFMmode. It switches in PFM mode for light loadconditions and for large buck conversion ratios. Thisresults in a higher efficiency over all load ranges. TheMCP16312 runs in PWM-only mode, and isrecommended for noise-sensitive applications.The MCP16311/2 can supply up to 1Aof continuouscurrent while regulating the output voltage from 2V to12V. An integrated, high-performance peak currentmode architecture keeps the output voltage tightlyregulated, even during input voltage steps and outputcurrent transient conditions common in power systems.The EN input is used to turn the device on and off.While off, only a few micro amps of current areconsumed from the input.Output voltage is set with an external resistor divider.The MCP16311/2 is offered in small MSOP-8 and2 x 3 mm TDFN surface mount packages.
2.Typical Applications
3.Why choose us?
100% new and originao with Advantage price
High efficiency
Fast Delivery
Professional team service
10 Years Experience Electronic components
Electronic components Agent
Advantage logistic discount
Excellent After-sales Service.
