S-1142B33I-E61U Electronic Integrated Circuits LDO Voltage Regulators ABLIC
1.The S-1142A/BxxH Series, developed by using high-withstand voltage CMOS technology, is a positive voltage regulator with a high-withstand voltage, low current consumption, and high-accuracy output voltage.
The S-1142A/BxxH Series operates at a high maximum operating voltage of 50 V and a low current consumption of 4.0
A typ. In addition to a built-in low on-resistance transistor which provides a very small dropout voltage and a large output current, this voltage regulator also has a built-in ON / OFF circuit.
An overcurrent protection circuit prevents the load current from exceeding the capacitance of the output transistor, and a built-in thermal shutdown circuit prevents damage caused by heat.
A high heat radiation HSOP-6 package enables high-density mounting
2. Features
Output voltage: 2.0 V to 15.0 V, selectable in 0.1 V step
Input voltage: 3.0 V to 50 V
Input and output capacitors:A ceramic capacitor of 0.1 F or more can be used.
Built-in overcurrent protection circuit:
Limits overcurrent of output transistor. Built-in thermal shutdown circuit: Prevents damage caused by heat.
Built-in ON / OFF circuit: Ensures long battery life.
Operation temperature range: Ta = -40°C to +105°C Lead-free (Sn 100%), halogen-free
3.Applications
Constant-voltage power supply for electrical application for vehicle interior
Constant-voltage power supply for home electric appliance
