ALC5633Q-GRT 192khz PCM Interface Sound Card Driver REALTEK

ALC5633Q-GRT 192khz PCM Interface Sound Card Driver REALTEK

  • ALC5633Q-GRT 192khz PCM Interface Sound Card Driver REALTEK
ALC5633Q-GRT 192khz PCM Interface Sound Card Driver REALTEK
Product Details:
Place of Origin: TAIWAN
Brand Name: REALTEK
Certification: ROHS
Model Number: ALC5633Q-GRT
Payment & Shipping Terms:
Minimum Order Quantity: 10PCS
Packaging Details: 4000PCS/REEL
Delivery Time: 2-3DAYS
Payment Terms: T/T, Western Union
Supply Ability: 16000PCS/WEEK
Contact Now
Detailed Product Description
Operating Power Supply Voltage: 2.3V To 3.6V Digital Power Supply From: 1.8V To 3.6V
Line3_l / R Stereo: Single-ended Analog Input Support Play: Soft Mute, Digital Volume, Digital AVC
High Light:

PCM Interface Sound Card Driver


PCM Interface Sound Card Driver


ALC5633Q-GRT Audio DAC

ALC5633Q-GRT Electronic Integrated Circuits Sound card driver. Realtek High Definition Audio Manager

I2S audio DAC + headphone amplifier
1. General description
This is a highly integrated alc5634 I2S/PCM interface audio DAC with multiple input/output ports and is designed for multimedia handheld devices. It provides a stereo high-fidelity DAC playback via I2S/PCM interface.
To reduce the number of components, alc5634 can be connected to:
linein_l/R stereo single-ended analog input can be configured as differential analog input
auxin_l/R stereo single-ended analog input can be configured as differential analog input
line3_l/R stereo single-ended analog input
Single-ended stereo headphone output
Stereo Bridge Load (BTL) line_out
Multiple analog input and output pins provide seamless integration of wireless communication devices with analog connections. The differential input/output connection effectively reduces noise interference and provides better sound quality.
The alc5634 AVDD operates from a supply voltage of 2.3V to 3.6V. dcvdd and dbvdd operate from 1.8 to 3.6V. In order to extend battery life, each segment can be individually powered off under software control. Less than 10μA in the maximum energy saving state. Leakage current
The alc5634 is available in a 5X5mm'green' qfn-32 package, making it very suitable for use in handheld portable systems.
2. Features
Digital to analog converter and 100dB signal-to-noise ratio, and -86db THD + N at 3.3V
Three analog stereo single-ended or differential inputs, one stereo, linein_l/R, auxin_l/R, and line3_l/R
Stereo BTL (bridging load) line_out
Support play soft mute, digital volume, digital AVC
On-chip 45mW headphone driver stereo headphone output (AVDD = 3.3V, 16 load)
Support popular noise suppression and external capacitor
Digital power supply from 1.8V to 3.6V
Analog power supply and headphones from 2.3V to 3.6V power supply
Power management and enhanced power saving
The internal phase locked loop can receive a wide range of clock input
Support sampling rate 8khz ~ 192khz
Support I2C control interface
Support three programmable data interfaces
I2S, left-justified, or DSP
16/20/24 bit word length
Master or slave clock mode
Small size 32-pin QFN 5X5mm package
3. Application: portable media player
MP3 player
Bluetooth A2DP (Advanced Audio Distribution) headset
Portable Navigation Device (PND)
Multimedia phone

Q1. What is your terms of packing?

A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.


Q2. What is your MOQ?

A: We provide you small MOQ for each item, it depends your specific order!


Q3. Do you test or check all your goods before delivery?

A: Yes, we have 100% test and check all goods before delivery.


Q4: How do you make our business long-term and good relationship?

A:We keep good quality and competitive price to ensure our customers benefit ;

We respect every customer as our friend and we sincerely do business and make friends with them,It's not something that can be replaced.


Q5: How to contact us?
A: Send your inquiry details in the below,Click "Send"Now!!!
