MP2451DT-LF-Z Non Sync Buck 600mA 36V 2MHz Switching Regulator

MP2451DT-LF-Z Non Sync Buck 600mA 36V 2MHz Switching Regulator

MOQ: 10PCS
Price: NEGOTIABLE
Standard Packaging: 3000PCS/REEL
Delivery Period: 2-3DAYS
Payment Method: T/T, Western Union
Supply Capacity: 90000PCS/WEEK
Detail Information
Place of Origin
CHINA
Brand Name
MPS
Certification
ROHS
Model Number
MP2451DT-LF-Z
Product Category:
Switching Regulator
Output Voltage:
800 MV
Output Current:
600 MA
Maximum Input Voltage:
36 V
Minimum Input Voltage:
3.3 V
Switching Frequency:
2 MHz
Package / Box:
SOT-23-6
Factory Packing Quantity:
3000
Highlight:

600mA Switching Regulator

,

Non Sync Buck Switching Regulator

,

MP2451DT-LF-Z

Product Description

MP2451DT-LF-Z ELECTRONIC INTEGRATED CIRCUITS SWITCHING REGULATOR 600mA 36V 2MHz Non-sync Buc





                                                 1.DESCRIPTION

The MP2451 is a high frequency (2MHz) step-down switching regulator with integrated internal high-side high voltage power MOSFET. It provides single 0.6A (or less) highly efficient output with current mode control for fast loop response. The wide 3.3V to 36V input range accommodates a variety of step-down applications in automotive input environment. A 3μA shutdown mode quiescent current allows use in battery-powered applications. High power conversion efficiency over a wide load range is achieved by scaling down the switching frequency at light load condition to reduce the switching and gate driving losses. Frequency fold-back helps prevent inductor current runaway during start-up. Thermal shutdown provides reliable, fault-tolerant operation. The MP2451 is available in the cost-effective SOT23-6 and TSOT23-6 packages.

                                                   2.FEATURES
130μA Operating Quiescent Current
 Wide 3.3V to 36V Operating Input Range
 500mΩ Internal Power MOSFET
 2MHz fixed Switching Frequency
 Internally compensated
 Stable with Ceramic Output Capacitors
 Internal Soft-Start
 Precision Current Limit Without Current Sensing Resistor
 > 90% Efficiency
 Output Adjustable from +0.8V to 0.8xVIN
 3μA Low Shutdown Supply Current
 SOT23-6 and TSOT23-6 Packages APPLICATIONS
 High Voltage Power Conversion
 Automotive Systems
 Industrial Power Systems
 Distributed Power Systems
 Battery Powered Systems

MP2451DT-LF-Z Non Sync Buck 600mA 36V 2MHz Switching Regulator 0

MP2451DT-LF-Z Non Sync Buck 600mA 36V 2MHz Switching Regulator 1
