| MOQ: | 500PCS |
| Price: | Negotiation |
| Standard Packaging: | 4000PCS/BOX |
| Delivery Period: | 2-3DAYS |
| Payment Method: | T/T, Western Union |
| Supply Capacity: | 4000PCS/WEEK |
Documents
3D Model Application Specification AS-5557-001-001 (PDF) Drawing (PDF) Packaging Specification PK-5559-001-001 (PDF) Product Specification PS-45750-001-001 (PDF) RoHS Certificate of Compliance (PDF) Product Specification PS-5556-001-001 (PDF) Agency Certification CSA LR19980 UL E29179 General Product Family Crimp Housings Series 5559 3D Viewer Yes Application Power, Wire-to-Board, Wire-to-Wire Comments Current = 13A max. per circuit when header is mated to a receptacle loaded with 45750 series terminals crimped to 16 AWG wire. . See Molex product specification PS-45750-001 for additional current derating information. Comments Current = 13A max. per circuit when header is mated to a receptacle loaded with 45750 series terminals crimped to 16 AWG wire. . See Molex product specification PS-45750-001 for additional current derating information. Overview Mini-Fit Jr. Power Connectors Product Name Mini-Fit Jr. UPC 800753584303 Physical Breakaway No Circuits (maximum) 4 Color - Resin Natural Flammability 94V-2 Gender Plug Glow-Wire Capable No Material - Resin Nylon Net Weight 1.744/g Number of Rows 2 Packaging Type Bag Panel Mount Yes Pitch - Mating Interface 4.20mm Pitch - Termination Interface 4.20mm Polarized to Mating Part Yes Stackable No Temperature Range - Operating -40° to +105°C Electrical Current - Maximum per Contact 13.0A Solder Process Data Lead-freeProcess Capability N/A
|
|
