Magnetic Sensor Electronic Integrated Circuits Toshiba TCS40DPR LF Board Machine Interface

                                                              Product Instructions

Absolute Maximum Ratings (Ta = 25°C)
Characteristics Symbol Rating Unit
Supply Voltage VCC −0.5 to 6.0 V
Output Voltage VOUT −0.5 to 6.0 V
Output Diode Current IOK ±10 mA
Output Current IOUT ±5 mA
Vcc/GND Current ICC ±10 mA
Power Dissipation PD 1 (Note 2) W
Storage Temperature Range Tstg −65 to 150 °C
Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even
if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum
ratings and the operating ranges.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Note 2: Mounted on a FR4 board.
