|Place of Origin:||TH/TW|
|Minimum Order Quantity:||168PCS/BOX|
|SPQ:||168PCS/BOX||L/T:||STOCK ON HAND|
micro integrated circuit,
integrated circuit components
EZ-USBFX3:SuperSpeed USB Controller
■ Universal serial bus (USB) integration
❐ USB 3.1, Gen 1 and USB 2.0 peripherals compliant with USB
3.1 Specification Revision 1.0 (TID # 340800007)
❐ 5-Gbps SuperSpeed PHY compliant with USB 3.1 Gen 1
❐ High-speed On-The-Go (HS-OTG) host and peripheral
compliant with OTG Supplement Version 2.0
❐ Thirty-two physical endpoints
■ General Programmable Interface (GPIF™ II)
❐ Programmable 100-MHz GPIF IIenables connectivity to a
wide range of external devices
❐ 8-, 16-, 24-, and 32-bit data bus
❐ Up to16 configurable control signals
■ Fully accessible 32-bit CPU
❐ ARM926EJ core with 200-MHz operation
❐ 512-KB or 256-KB embedded SRAM
■ Additional connectivity to the following peripherals
❐ SPI master at up to 33 MHz
❐ UART support of up to 4 Mbps
C master controller at 1 MHz
S master (transmitter only) at sampling frequencies of
8 kHz, 16 kHz, 32 kHz, 44.1 kHz, 48 kHz, 96 kHz and 192 kHz
■ Selectable clock input frequencies
❐ 19.2, 26, 38.4, and 52 MHz
❐ 19.2-MHz crystal input support
■ Ultra low-power in core power-down mode
❐ Less than 60 µA with VBATT on and 20 µA with VBATT off
■ Independent power domains for core and I/O
❐ Core operation at 1.2 V
❐ I2S, UART, and SPI operation at 1.8 to 3.3 V
C operation at 1.2 V to 3.3 V
■ Package options
❐ 121-ball, 10- × 10-mm, 0.8-mm pitch Pb-free ball grid array
❐ See Table 24for details on the seven FX3 variants
Software Development Kit (SDK) for code development of firmware and PC Applications
❐ Includes RTOS Framework (using ThreadX Version 5)
❐ Firmware examples covering all I/O modules
❐ Visual Studio host examples using C++ and C#
■ SuperSpeed Explorer Board available for rapid prototyping
❐ Several accessory boards also available:
• Adapter boards for Xilinx/Altera FPGA development
• Adapter board for Video development
• CPLD board for concept testing and initial development
■ Digital video camcorders
■ Digital still cameras
■ Video capture cards
■ Test and measurement equipment
■ Surveillance cameras
■ Personal navigation devices
■ Medical imaging devices
■ Video IP phones
■ Portable media players
■ Industrial cameras
■ Data loggers
■ Data acquisition
■ High-performance Human Interface Devices (gesture
For a complete list of related documentation, click here.
