Place of Origin: | MEX |
Brand Name: | Texas Instruments |
Certification: | ROHS |
Model Number: | PTH12060WAH |
Minimum Order Quantity: | 1PCS |
---|---|
Price: | Negotiation |
Packaging Details: | 36PCS |
Delivery Time: | 3-5DAYS |
Payment Terms: | T/T, Western Union |
Supply Ability: | 5000PCS |
Product Category: | Non-Isolated DC/DC Converters | Product: | Non-Isolated / POL |
---|---|---|---|
Number Of Outputs: | 1 Output | Input Voltage, Nominal: | 12V |
Input Voltage, Min: | 10.8V | Input Voltage, Max: | 13.2V |
Output Voltage-Channel 1: | 1.2 V To 5.5 V | Output Current-Channel 1: | 10A |
Minimum Operating Temperature: | -40C | Maximum Operating Temperature: | +85C |
Mounting Style: | Through Hole | Length: | 25.3MM |
Width: | 15.75MM | Height: | 9.6MM |
Input Voltage: | 10.8 V To 13.2 V | Output Type: | Single |
Package / Case: | Module | Packaging: | Tray |
Industry: | Industria | Moisture Sensitive: | Yes |
Product Type: | Non-Isolated DC-DC Converter | Factory Pack Quantity: | 36 |
Tradename: | POLA | ||
High Light: | gps gprs module,smallest gsm module |
SLTS217H
2• Up to 10-A Output Current • Complex Digital Systems
• 12-V Input Voltage
• Wide-Output Voltage Adjust
(1.2 V to 5.5 V/(0.8 V to 1.8 V)
• Efficiencies up to 95%
• 225 W/in3
Power Density
• Output Voltage Sense
• Margin Up/Down Controls
• Undervoltage Lockout
• Auto-Track™ Sequencing
• Pre-Bias Start-up Capability
using On/Off Inhibit
• Output Overcurrent Protection
(Non-latching, Auto-Reset)
• Operating Temperature: –40°C to 85°C
• Safety Agency Approvals:
UL/IEC/CSA C22.2 60950-1
• Point-of-Load Alliance (POLA™) Compatible
The PTH12060 series is a non-isolated power module, and part of a new class of complete dc/dc converters
from Texas Instruments. These modules are small in size, and are an alternative for applications requiring up to
10 A of load current.
The small footprint, (1 inch × 0.62 inch) and industry leading features makes this module suitable for space
conscious digital systems that incorporate multiple processors.
This series of modules operate from a 12-V input bus voltage to provide step-down power conversion to a wide
range of output voltages. The output voltage of the W-suffix device may be set to any voltage over the adjust
range, 1.2 V to 5.5 V. The L-suffix device has an adjustment range of 0.8 V to 1.8 V. The output voltage is set
within the adjust range using a single external resistor.
This product includes Auto-Track™ Sequencing. Auto-Track simplifies the task of supply voltage sequencing in a
power system, by enabling modules to track each other, or any other external voltage, during power up and
power down.
Other features include an on/off inhibit and margin up/down controls. An output voltage sense ensures tight load
regulation. Non-latching overcurrent trip protects against load faults.
Products with this feature incorporate an output voltage sense pin, VO Sense. A remote sense improves the load regulation performance of the module by allowing it to compensate for any IR voltage drop between its output and the load. An IR drop is caused by the high output current flowing through the small amount of pin and trace resistance. To use this feature simply connect the VO Sense pin to the VO node, close to the load circuit (see data sheet standard application circuit). If a sense pin is left open-circuit, an internal low-value resistor (15-Ω or less) connected between the pin and the output node, ensures the output remains in regulation. With the sense pin connected, the difference between the voltage measured directly between the VO and GND pins, and that measured from VO Sense to GND, is the amount of IR drop being compensated by the regulator. This should be limited to a maximum of 0.3 V. Note: The remote sense feature is not designed to compensate for the forward drop of nonlinear or frequency dependent components that may be placed in series with the converter output. Examples include OR-ing diodes, filter inductors, ferrite beads, and fuses. When these components are enclosed by the remote sense connection, they are effectively placed inside the regulation control loop, which can adversely affect the stability of the regulator. For protection against load faults, all modules incorporate output overcurrent protection. Applying a load that exceeds the regulator's overcurrent threshold causes the regulated output to shut down. Following shutdown, a module periodically attempts to recover by initiating a soft-start power-up. This is described as a hiccup mode of operation, whereby, the module continues in a cycle of successive shutdown and power up until the load fault is removed. During this period, the average current flowing into the fault is significantly reduced. Once the fault is removed, the module automatically recovers and returns to normal operation. The PTH12020, PTV12020, and PTH12030 products have overtemperature protection. These products have an on-board temperature sensor that protects the module's internal circuitry against excessively high temperatures. A rise in the internal temperature may be the result of a drop in airflow, or a high ambient temperature. If the internal temperature exceeds the OTP threshold, the module's Inhibit control is internally pulled low. This turns the output off. The output voltage drops as the external output capacitors are discharged by the load circuit. The recovery is automatic, and begins with a soft-start power up. It occurs when the sensed temperature decreases by about 10°C below the trip point. Note: The overtemperature protection is a last resort mechanism to prevent thermal stress to the regulator. Operation at or close to the thermal shutdown temperature is not recommended and will reduce the long-term reliability of the module. Always operate the regulator within the specified Safe Operating Area (SOA) limits for the worst-case conditions of ambient temperature and airflow
