FF300R12KT4 Infineon IGBT Module 100% Original Digital Integrated Circuit
2.5 kV rms signal and power isolated CAN transceiver
isoPower integrated isolated dc-to-dc converter5 V operation on VCC
5 V or 3.3 V operation on VIOComplies with ISO 11898 standard
High speed data rates of up to 1 MbpsUnpowered nodes do not disturb the bus
Connect 110 or more nodes on the busSlope control for reduced EMI
Thermal shutdown protectionHigh common-mode transient immunity: >25 kV/μsSafety and regulatory approvals
UL recognition2500 V rms for 1 minute per UL 1577
CSA Component Acceptance Notice 5A
VDE Certificate of Conformity
DIN EN 60747-5-2 (VDE 0884 Part 2): 2003-01
VIORM = 560 V peak
Industrial operating temperature range (−40°C to +85°C)
Available in wide-body, 20-lead SOIC package
APPLICATIONSCAN data busesIndustrial field networks
The ADM3053 is an isolated controller area network (CAN)
physical layer transceiver with an integrated isolated dc-to-dc
converter. The ADM3053 complies with the ISO 11898 standard.
The device employs Analog Devices, Inc., iCoupler® technology
to combine a 2-channel isolator, a CAN transceiver, and Analog
Devices isoPower® dc-to-dc converter into a single SOIC surface
mount package. An on-chip oscillator outputs a pair of square
waveforms that drive an internal transformer to provide isolated
power. The device is powered by a single 5 V supply realizing a
fully isolated CAN solution.The ADM3053 creates a fully isolated interface between theCAN protocol controller and the physical layer bus. It is capableof running at data rates of up to 1 Mbps.The device has current limiting and thermal shutdown featuresto protect against output short circuits. The part is fully specifiedover the industrial temperature range and is available in a20-lead, wide-body SOIC package.The ADM3053 contains isoPower technology that uses highfrequency switching elements to transfer power through thetransformer. Special care must be taken during printed circuitboard (PCB) layout to meet emissions standards. Refer to theAN-0971 Application Note, Recommendations for Control of
Radiated Emissions with isoPower Devices, for details on boardlayout considerations.
